Zirconia Crucible Zirconium Oxide Ceramic Crucible Cylindrical

The zirconia crucible endures high temperatures, acids, and alkalis, exhibiting excellent corrosion resistance and thermal shock resistance. It is frequently employed in chemical analysis experiments conducted at elevated temperatures, as well as industrial material testing and analysis, used to heat and melt various materials for the examination of their physical and chemical properties.

Brand:
ATCERA
Item NO.:
AT-YHG-Y001

Materials
Zirconia
Shapes
Crucible
Applications
Mechanical Parts , Petrochemical Industry , Metallurgy Industry , Lithium Battery Production

Inquire Now

Advantages of ZrO₂ Ceramic Crucible Cylindrical

1. High temperature resistance, the highest working temperature can reach up to 2200℃.

2. Good thermal shock resistance, can maintain good thermal stability at high temperature.

3. Cylindrical crucible can be made into large volume and easy to operate.

Applications of Yttria Stabilized Zirconia (YSZ) Crucible

Applications of Zirconia Ceramic Crucible Cylindrical

1. Zirconia crucible can be used in various industrial thermal analysis, melting metal and non-metallic material samples.

2. Zirconia crucible is widely used in metal processing, glass melting, jewelry industry gem purification and other high temperature applications.

3. Cylindrical crucible is suitable for melting and processing of various materials, good consistency, to meet the needs of batch analysis or production.

Size Chart of Zirconia Ceramic Crucible Cylindrical

We are committed to delivering optimal zirconium oxide cylindrical crucible tailored to your exact specifications. Our dedicated team ensures meticulous adherence to your instructions, striving to exceed customer expectations. Additionally, we offer the flexibility of custom sizes to accommodate your unique requirements.

Send Requirements for Custom Design

Requirements for Custom Design

1. Drawing (requirements of material, size, tolerance standard, etc. could be attached) and other specification requirements.

2. Application scenario

Drawing of Zirconia Ceramic Crucible Cylindrical

Zirconia Ceramic Crucible Cylindrical
Item No.	Outer Diamete (mm)	Inner Diameter (mm)	Height (mm)	Wall Thickness (mm)	Volume (ml)	ZrO₂'s Purity (%)
AT-YHG-Y001	20.0	16.0	19.0	2.0	4	95
AT-YHG-Y002	24.0	20.0	50.0	2.0	15	95
AT-YHG-Y003	29.5	22.7	29.6	3.4	11	95
AT-YHG-Y004	32.0	24.0	26.0	4.0	11	95
AT-YHG-Y005	32.0	23.0	30.0	4.5	12	95
AT-YHG-Y006	33.5	27.0	59.0	3.3	33	95
AT-YHG-Y007	33.5	27.5	69.5	3.0	40	95
AT-YHG-Y008	35.0	28.0	31.0	3.5	18	95
AT-YHG-Y009	39.0	34.0	62.0	2.5	55	95
AT-YHG-Y010	40.0	31.0	55.0	4.5	40	95
AT-YHG-Y011	42.5	34.0	59.0	4.3	52	95
AT-YHG-Y012	29.5	23.0	100.0	3.3	41	95
AT-YHG-Y013	44.8	36.0	30.0	4.4	28	95
AT-YHG-Y014	45.0	37.0	103.0	4.0	109	95
AT-YHG-Y015	50.0	40.0	106.0	5.0	130	95
AT-YHG-Y016	50.5	42.0	71.0	4.3	95	95
AT-YHG-Y017	51.0	42.0	84.3	4.5	114	95
AT-YHG-Y018	51.0	42.0	84.0	4.5	113	95
AT-YHG-Y019	51.0	44.0	102.0	3.5	152	95
AT-YHG-Y020	59.0	51.0	91.0	4.0	182	95
AT-YHG-Y021	62.0	55.0	97.0	3.5	226	95
AT-YHG-Y022	69.0	50.0	118.0	9.5	222	95
AT-YHG-Y023	70.0	50.0	200.0	10.0	383	95
AT-YHG-Y024	70.0	60.0	12.0	5.0	27	95
AT-YHG-Y025	72.5	50.0	135.0	11.3	254	95
AT-YHG-Y026	77.0	69.0	85.0	4.0	310	95
AT-YHG-Y027	78.0	57.0	89.0	10.5	214	95
AT-YHG-Y028	80.0	59.0	143.0	10.5	377	95
AT-YHG-Y029	85.0	75.0	109.0	5.0	471	95
AT-YHG-Y030	86.0	69.0	160.0	8.5	582	95
AT-YHG-Y031	87.0	69.0	165.0	9.0	600	95
AT-YHG-Y032	107.0	82.0	128.0	12.5	643	95
AT-YHG-Y033	118.0	83.0	133.0	17.5	672	95
AT-YHG-Y034	59.0	51.0	92.0	4.0	184	95
AT-YHG-Y035	23.0	18.0	94.0	2.5	24	95
AT-YHG-Y036	11.5	8.8	55.6	1.4	3	95
AT-YHG-Y037	11.5	8.8	45.8	1.4	3	95
AT-YHG-Y038	16.8	9.2	9.2	3.8	2	95
AT-YHG-Y039	15.0	12.0	13.0	1.5	1	95
AT-YHG-Y040	51.0	43.0	85.0	4.0	121	95
AT-YHG-Y041	40.0	35.0	32.0	2.5	30	95
AT-YHG-Y042	43.0	34.0	102.0	4.5	91	95
AT-YHG-Y043	29.0	25.0	30.0	2.0	14	95
AT-YHG-Y044	42.0	35.0	102.0	3.5	96	95
AT-YHG-Y045	50.0	40.0	118.0	5.0	145	95
AT-YHG-Y046	26.0	21.0	85.0	2.5	29	95
AT-YHG-Y047	41.0	35.0	58.0	3.0	54	95
AT-YHG-Y048	29.0	25.0	42.0	2.0	20	95
AT-YHG-Y049	31.0	26.0	76.0	2.5	40	95
AT-YHG-Y050	32.0	23.0	30.0	4.5	12	95
AT-YHG-Y051	37.0	28.0	33.0	4.5	19	95
AT-YHG-Y052	62.0	55.0	97.0	3.5	226	95
AT-YHG-Y053	85.0	76.0	110.0	4.5	489	95
AT-YHG-Y054	10.5	7.7	25.0	1.4	2	95
AT-YHG-Y055	13.0	10.2	25.0	1.4	3	95
AT-YHG-Y056	18.0	16.0	26.0	1.0	5	95
AT-YHG-Y057	22.0	18.8	33.0	1.6	9	95
AT-YHG-Y058	15.0	11.0	100.0	2.0	9	95
AT-YHG-Y059	50.0	44.0	80.0	3.0	120	95
AT-YHG-Y060	30.0	26.0	60.0	2.0	35	95
AT-YHG-Y061	42.0	38.0	53.0	2.0	37	95
AT-YHG-Y062	57.0	53.0	65.0	2.0	100	95
AT-YHG-Y063	48.0	44.0	52.0	2.0	50	95
AT-YHG-Y064	38.0	34.0	45.0	2.0	30	95
AT-YHG-Y065	9.0	6	15.0	1.5	2	95
AT-YHG-Y066	16.0	11.0	12.0	2.5	3	95
AT-YHG-Y067	16.0	11.0	95.0	2.5	10	95
AT-YHG-Y068	32.0	26.0	80.0	3.0	40	95
AT-YHG-Y069	34.0	28.0	80.0	3.0	50	95
AT-YHG-Y070	36.0	30.0	80.0	3.0	60	95
AT-YHG-Y071	40.0	34.2	50.0	2.9	50	95
AT-YHG-Y072	40.0	34.2	80.0	2.9	70	95
AT-YHG-Y073	45.0	39.2	50.0	2.9	50	95
AT-YHG-Y074	50.0	42.0	80.0	4.0	100	95
AT-YHG-Y075	57.0	49.0	75.0	4.0	120	95
AT-YHG-Y076	66.0	59.4	66.0	3.3	120	95
AT-YHG-Y077	80.0	73.0	80.0	3.5	300	95

Technical Data of Zirconium Oxide Materials

Material	Zirconia (ZrO₂)+ Stabilizing agent
Thermal Conductivity	3.0w/m.k
Temperature resistance	1000℃
Density	5.65-6.05g/cm3
Thermal Expansion Coefficient	0.00001/℃
Bending Strength	480-1000MPa
Hardness (Hv)	1200-1450HV1
Fracture Toughness	*6-8MPam1/2**
Hazardous Substances	In compliance with EU ROHS standards

*This chart illustrates the standard characteristics of the zirconia materials commonly employed in the manufacturing of our zirconia products and parts. Please be aware that the attributes of customized zirconium oxide products and parts may vary depending on the specific processes involved. Detailed parameter is decided by type and composition of stabilizing agent.

Usage Instructions

1. Can not use gasoline spray gun, acetylene gun, alcohol burner to heat the zirconia crucible directly.

2. Before using the zirconia crucible for the first time, put it in the oven at about 105℃ for 120 minutes to remove the water on crucible surface.

3. Heating/cooling speed should not be too fast, below 1200℃ shall not over 5℃/ min; and above 1200℃ shall be controlled within 4℃/ min, too fast heating or cooling may lead to crucible cracking.

4. The distance between the crucible and the heating body (silicon carbon heting tube, heating rod or heating wire) should be no less than 2cm.

5. The bottom should not be in direct contact with the bottom of the furnace. It is recommended to use corundum pieces and other temperature resistant substances to lift the crucible to form air convection.

6. The material should be added according to the volume of the crucible, and should not be squeezed too tightly to avoid the metal thermal expansion and cause crack of the crucible.

7. When taking out the metal molten liquid, scoop it out with a spoon, in the case that caliper need to be used, avoid excessive force on the crucible which may shorten the service life.

8. Safety during use: zirconia crucible works at high temperature, and personal protective equipment such as heat-releasing gloves and protective glasses should be worn when using to avoid burns or eye injuries.

9. Storage: when store zirconia crucible, it should be placed in a dry and ventilated place to avoid friction or collision with other items, so as not to scratch or damage the surface of the crucible.

Valuable Information

Production Process Flow

1. Dry pressing forming

2. Hot pressing casting

3. Medium temperature dewaxing

4. High temperature sintering

5. Centerless grinding

6. Internal grinding

7. External grinding

8. Plane grinding

9. Honing and polishing

Customization Advantages

1. According to your application scenario, analyze the needs, choose the appropriate material and processing plan.

2. Professional team, quick response, can provide solutions and quotations within 24 hours after confirming the demand.

3. Flexible business cooperation mechanism, support at least one piece of quantity customization.

4. Quickly provide samples and test reports to confirm that the product meets your needs.

5. Provide product use and maintenance suggestions to reduce your cost of use.
