Magnesia Ceramic Tube Magnesium Oxide Pipe

Magnesium oxide ceramic tube is resistant to high temperature and corrosion, also with good electrical insulation, can be used as electric heater protection tube, thermocouple protection tube, cable insulation tube, etc.

Brand:
ATCERA
Item NO.:
AT-MO-G1001

Materials
MgO
Shapes
Tube
Applications
Electronics and Electricity , Metallurgy Industry

Inquire Now

Advantages of Magnesium Oxide Tube

Magnesium oxide ceramic tube is resistant to high temperature and corrosion, can resist over 2000℃ temperature, and can contact directly to various chemical substance, also with good electrical insulation.

Applications of Magnesia Ceramic Tube

Magnesium oxide ceramic tube can be used as electric heater protection tube, thermocouple protection tube, cable insulation tube, etc.

Product Parameters
Material Parameters

Size Chart of Magnesia Ceramic Tube

Committed to providing optimal magnesia ceramic tube customized to your precise needs. Our devoted team guarantees careful adherence to your instructions, aiming to surpass customer expectations. Moreover, we provide the flexibility of customized sizes to meet your unique requirements.

Send Requirements for Custom Design

Please provide drawing and parameter requirements for customization.

Magnesia Ceramic Tube Single-bore
Item NO.	Outer Diameter (mm)	Inner Diameter (mm)	Length (mm)	Purity (%)
AT-MO-G1001	1.2	0.5	30	99.5
AT-MO-G1002	3.7	2.0	30	99.5
AT-MO-G1003	3.9	1.3	30	99.5
AT-MO-G1004	5.0	2.0	30	99.5
AT-MO-G1005	5.0	3.0	30	99.5
AT-MO-G1006	5.5	2.0	30	99.5
AT-MO-G1007	6.4	3.4	40	99.5
AT-MO-G1008	7.0	4.0	40	99.5
AT-MO-G1009	8.0	5.0	40	99.5
AT-MO-G1010	9.0	6.0	40	99.5
AT-MO-G1011	13.0	9.0	50	99.5
AT-MO-G1012	14.0	8.0	50	99.5
AT-MO-G1013	15.0	10.0	50	99.5
AT-MO-G1014	16.0	9.0	50	99.5
AT-MO-G1015	18.0	10.0	50	99.5
AT-MO-G1016	19.0	19.0	50	99.5
AT-MO-G1017	1.2-25	0.5-20	30-500	99.5

Magnesia Ceramic Tube Double-bores
Item NO.	Outer Diameter (mm)	Inner Diameter (mm)	Length (mm)	Purity (%)
AT-MO-G2001	5.3	1.6	25	99.5
AT-MO-G2002	7.0	2.4	40	99.5
AT-MO-G2003	9.0	3.0	50	99.5
AT-MO-G2004	11.0	3.5	40	99.5
AT-MO-G2005	15.0	4.5	40	99.5
AT-MO-G2006	18.0	5.0	50	99.5
AT-MO-G2007	13.0	4.5	40	99.5
AT-MO-G2008	20.0	6.0	50	99.5

Magnesia Ceramic Tube Three-bores
Item NO.	Outer Diameter (mm)	Inner Diameter (mm)	Length (mm)	Purity (%)
AT-MO-G3001	6.6	1.3	50	99.5
AT-MO-G3002	6.6	1.3	100	99.5
AT-MO-G3003	9	3	50	99.5
AT-MO-G3004	13.6	2.3	50	99.5
AT-MO-G3005	18	5	100	99.5
AT-MO-G3006	20	6	100	99.5

Magnesia Ceramic Tube Four-bores
Item NO.	Outer Diameter (mm)	Inner Diameter (mm)	Length (mm)	Purity (%)
AT-MO-G4001	4.0	1.1	20	99.5
AT-MO-G4002	5.0	1.3	25	99.5
AT-MO-G4003	6.0	1.4	25	99.5
AT-MO-G4004	7.0	1.6	25	99.5
AT-MO-G4005	8.0	1.8	25	99.5
AT-MO-G4006	9.0	2.5	25	99.5
AT-MO-G4007	11.0	3.0	40	99.5
AT-MO-G4008	12.0	3.5	40	99.5
AT-MO-G4009	13.0	4.0	40	99.5
AT-MO-G4010	15.0	4.0	50	99.5
AT-MO-G4011	16.0	4.0	40	99.5
AT-MO-G4012	17.0	5.0	50	99.5
AT-MO-G4013	18.0	5.0	50	99.5
AT-MO-G4014	19.0	5.5	50	99.5
AT-MO-G4015	20.0	5.5	50	99.5
AT-MO-G4016	22.0	6.0	50	99.5
AT-MO-G4017	24.0	6.8	50	99.5
AT-MO-G4018	25.0	7.0	50	99.5
AT-MO-G4019	26.0	7.0	50	99.5
AT-MO-G4020	28.0	8.0	50	99.5

Magnesia Ceramic Tube Seven-bores
Item NO.	Outer Diameter (mm)	Inner Diameter (mm)	Length (mm)	Purity (%)
AT-MO-G7001	9	1.8	25	99.5
AT-MO-G7002	11	2.5	25	99.5
AT-MO-G7003	13	3	30	99.5
AT-MO-G7004	15	3.5	35	99.5
AT-MO-G7005	17	4	40	99.5
AT-MO-G7006	18	4.5	40	99.5
AT-MO-G7007	20	4.5	50	99.5
AT-MO-G7008	22	5	50	99.5
AT-MO-G7009	25	5	50	99.5
AT-MO-G7010	27	7	50	99.5
AT-MO-G7011	29	7	50	99.5
AT-MO-G7012	33	7	50	99.5
AT-MO-G7013	48	8.3	50	99.5

Technical Data of Magnesium Oxide Materials

Purity (%)	>99%
Density (g/cm3)	3.52-3.56
Bending Strength (MPa)	18
Compressive Strength (MPa)	50
Hardness (Moh's)	6
Maximum Working Temperature (℃)	2200
*Thermal Conductivity (W/mK)**	5
Thermal Expansion Coefficient (/℃)	13*10^-6
*Volume Resistivity (Ohmcm)**	1*10¹³
Dielectric Strength (kV/mm)	5.8

*This chart illustrates the standard characteristics of the magnesium oxide materials commonly employed in the manufacturing of our magnesium oxide products and parts. Please be aware that the attributes of customized magnesium oxide products and parts may vary depending on the specific processes involved.

Valuable Information

Magnesia Ceramic Tubes Packing

High purity magnesia ceramic tubes are carefully packaged in appropriate containers to avoid any potential damage.

Customization Advantages

1. According to your application scenario, analyze the needs, choose the appropriate material and processing plan.

2. Professional team, quick response, can provide solutions and quotations within 24 hours after confirming the demand.

3. Flexible business cooperation mechanism, support at least one piece of quantity customization.

4. Quickly provide samples and test reports to confirm that the product meets your needs.

5. Provide product use and maintenance suggestions to reduce your cost of use.
