The alumina locating pin is crafted from high-purity alumina, boasting exceptional resistance to high temperatures, corrosion, and wear. Its primary function is to utilize component holes as a positioning reference, ensuring precise planar alignment between components.
Brand:
ATCERAItem NO.:
AT-YHL-DWX001Materials
AluminaShapes
Mechanical PartsApplications
Mechanical Parts , Petrochemical Industry , Metallurgy Industry
1. The alumina ceramic locating pin possesses superior hardness, wear resistance, high-temperature tolerance, oxidation resistance, and corrosion resistance, making it suitable for various harsh working environments.
2. Compared to metal locating pins, alumina ceramic pins are lighter in weight, contributing to the overall weight reduction of the system.
3. The alumina ceramic locating pin exhibits excellent electrical insulation, preventing electrical leakage and electrochemical corrosion of components.
Utilizing component holes as a positioning reference, the alumina locating pin maintains precise relative distances between components, restricts their movement freedom, and ensures the accuracy and stability of machine components. This guarantees the smooth operation of the entire machine, primarily in mechanical processing equipment, automated production lines, petrochemical, and metallurgical equipment.
We are committed to delivering optimal alumina ceramic pins tailored to your exact specifications. Our dedicated team ensures meticulous adherence to your instructions, striving to exceed customer expectations. Additionally, we offer the flexibility of custom sizes to accommodate your unique requirements.
Please provide drawings and parametric specifications for customization.
| Alumina Ceramic Locating Pin | ||||
| Item no. | Dimension (mm) |
Length (mm) |
Diameter (mm) |
Al2O3's Purity (%) |
| AT-YHL-DWX001 | 13.8*35.6 | 35.6 | 13.8 | 95-99 |
| AT-YHL-DWX002 | 8.7*32.5 | 32.5 | 8.7 | 95-99 |
| AT-YHL-DWX003 | 7.3*42.2 | 42.2 | 7.3 | 95-99 |
| AT-YHL-DWX004 | 5.6*32.4 | 32.4 | 5.6 | 95-99 |
| AT-YHL-DWX005 | 8*17.7 | 17.7 | 8 | 95-99 |
| AT-YHL-DWX006 | 8.7*34.3 | 34.3 | 8.7 | 95-99 |
| AT-YHL-DWX007 | 6*24.3 | 24.3 | 6 | 95-99 |
| AT-YHL-DWX008 | 5.8*21.6 | 21.6 | 5.8 | 95-99 |
| AT-YHL-DWX009 | 4.9*23.7 | 23.7 | 4.9 | 95-99 |
| AT-YHL-DWX010 | 13.6*33.4 | 33.4 | 13.6 | 95-99 |
| AT-YHL-DWX011 | 11*33.2 | 33.2 | 11 | 95-99 |
| AT-YHL-DWX012 | 6.9*25.7 | 25.7 | 6.9 | 95-99 |
| AT-YHL-DWX013 | 7.9*27.1 | 27.1 | 7.9 | 95-99 |
| AT-YHL-DWX014 | 10*30 | 30 | 10 | 95-99 |
| AT-YHL-DWX015 | 7.8*28.3 | 28.3 | 7.8 | 95-99 |
| AT-YHL-DWX016 | 8*25.5 | 25.5 | 8 | 95-99 |
| AT-YHL-DWX017 | 6.9*23.2 | 23.2 | 6.9 | 95-99 |
| AT-YHL-DWX018 | 6.8*22.6 | 22.6 | 6.8 | 95-99 |
| AT-YHL-DWX019 | 8.9*22 | 22 | 8.9 | 95-99 |
| AT-YHL-DWX020 | 10.4*23 | 23 | 10.4 | 95-99 |
| AT-YHL-DWX021 | 8.7*27.8 | 27.8 | 8.7 | 95-99 |
| AT-YHL-DWX022 | 7.7*27.4 | 27.4 | 7.7 | 95-99 |
| AT-YHL-DWX023 | 8.8*23.8 | 23.8 | 8.8 | 95-99 |
| AT-YHL-DWX024 | 8.6*24.2 | 24.2 | 8.6 | 95-99 |
| AT-YHL-DWX025 | 13*28.5 | 28.5 | 13 | 95-99 |
| AT-YHL-DWX026 | 8.8*27.3 | 27.3 | 8.8 | 95-99 |
| AT-YHL-DWX027 | 9.8*23.7 | 23.7 | 9.8 | 95-99 |
| AT-YHL-DWX028 | 8.5*25.2 | 25.2 | 8.5 | 95-99 |
| AT-YHL-DWX029 | 12*37 | 37 | 12 | 95-99 |
| AT-YHL-DWX030 | 8.7*27.7 | 27.7 | 8.7 | 95-99 |
| AT-YHL-DWX031 | 6.6*27.1 | 27.1 | 6.6 | 95-99 |
| AT-YHL-DWX032 | 19*29 | 29 | 19 | 95-99 |
| Material | 99% Alumina (AL2O3) |
| Thermal Conductivity | 24.0w/m.k |
| Electrical Insulation | ≤22.5KV, temperature resistance up to 1600℃ |
| Density | 3.83g/cm3 |
| Thermal Expansion Coefficient | 7*10-6/℃ |
| Bending Strength (at room temperature) | 310MPa |
| Compressive Strength (at room temperature) | 2200MPa |
| Hardness (Hv) | 1650 |
| Fracture Toughness | 4.2MPa*m1/2 |
*This chart illustrates the standard characteristics of the alumina materials commonly employed in the manufacturing of our alumina products and parts. Please be aware that the attributes of customized aluminum oxide products and parts may vary depending on the specific processes involved.
