Zirconia Ceramic Metering Pump ZrO2 Dosing Pump

Zirconia ceramic metering pump is a kind of high precision fluid metering component, the structure is simple, mainly by adjusting the plunger or pistion stroke to change the fluid flow volume, fluid inlet and outlet control is achieved through a three-way valve.

Brand:
ATCERA
Item NO.:
AT-ZP-1001

Materials
Zirconia
Shapes
Pump
Applications
Mechanical Parts , Petrochemical Industry , Food Processing

Inquire Now

Advantages of Zirconium Oxide Metering Pump

1. Strong corrosion resistance

Zirconia ceramic material has good corrosion resistance, the pump can be used to transport a variety of corrosive liquids, no pollution to the liquid；

2. High precision

The processing precision of zirconia ceramic material is high, which can meet the high precision metering requirements;

3. Long life time

Zirconia material hs high hardness and good wear resistance, so service life of zirconia metering pump is long;

4. Easy maintenance

The inner surface of zirconia ceramic metering pump is polished, metering liquid will not remain on the pump, which can reduce maintenance costs;

5. High safety

Zirconia material itself is non-toxic and harmless, good biological compatibility, no stimulation and side effects to human body.

Applications of Ceramic Dosing Pump

Zirconia ceramic metering pump is used to achieve precise metering and control of various liquids in the industrial field, such as food additives, chemical agents, etc.

1. Chemical industry

Zirconia metering pump can be used for acid, alkali, chloride, amine, solvent and other chemical substances flow measurement and control;

2. Petroleum industry

Zirconia metering pump can be used as a measuring device for lubricating oil, distillate oil and other processing raw materials to ensure the accuracy and stability of oil processing and production;

3. Food industry

Zirconia ceramic metering pumps can be used to control the amount of food additives added to maintain the quality and taste of food;

4. Water treatment

It can be used for water treatment and dosing pump,to remove water scale, maintain water quality, and inhibit bacteria and algae growth.

Size Chart of Zirconium Oxide Metering Pump

We are committed to delivering optimal zirconia metering pump tailored to your exact specifications. Our dedicated team ensures meticulous adherence to your instructions, striving to exceed customer expectations. Additionally, we offer the flexibility of custom sizes to accommodate your unique requirements.

Send Requirements for Custom Design

Custom Design

1. Customized metering pump is available for the range of 0.02-180ml, drawing and specification requirement shall be provided.

2. Machining tolerance is ±0.02mm, and the best metering accuracy can reach up to ±0.25%.

Zirconium Oxide Metering Pump
Item NO.	Volmue (ml)	Filling Accuracy (%)	ZrO₂'s Purity (%)
AT-ZP-1001	0.02	≤0.5%	95%
AT-ZP-1002	0.5	≤0.5%	95%
AT-ZP-1003	1	≤0.5%	95%
AT-ZP-1004	2	≤0.5%	95%
AT-ZP-1005	3	≤0.5%	95%
AT-ZP-1006	5	≤0.5%	95%
AT-ZP-1007	7	≤0.5%	95%
AT-ZP-1008	10	≤0.5%	95%
AT-ZP-1009	15	≤0.5%	95%
AT-ZP-1010	16	≤0.5%	95%
AT-ZP-1011	20	≤0.5%	95%
AT-ZP-1012	25	≤0.5%	95%
AT-ZP-1013	0.3	≤0.1%	95%
AT-ZP-1014	0.8	≤0.1%	95%
AT-ZP-1015	1.5	≤0.1%	95%
AT-ZP-1016	2.2	≤0.1%	95%
AT-ZP-1017	2.8	≤0.1%	95%
AT-ZP-1018	4	≤0.1%	95%
AT-ZP-1019	9	≤0.1%	95%
AT-ZP-1020	23	≤0.1%	95%
AT-ZP-1021	50	≤0.1%	95%
AT-ZP-1022	0.4	＞0.5%，＜1%	95%
AT-ZP-1023	2.1	＞0.3%，＜0.5%	95%
AT-ZP-1024	3.7	＞0.3%，＜0.5%	95%
AT-ZP-1025	6.4	＞0.3%，＜0.5%	95%
AT-ZP-1026	8	＞0.3%，＜0.5%	95%
AT-ZP-1027	7.5	＞0.3%，＜0.5%	95%
AT-ZP-1028	8.5	＞0.3%，＜0.5%	95%
AT-ZP-1029	35	＞0.3%，＜0.5%	95%
AT-ZP-1030	67	＞0.3%，＜0.5%	95%
AT-ZP-1031	100	＞0.3%，＜0.5%	95%
AT-ZP-1032	140	＞0.3%，＜0.5%	95%
AT-ZP-1033	180	＞0.3%，＜0.5%	95%

Technical Data of Zirconium Oxide Materials

Material	Zirconia (ZrO₂)+ Stabilizing agent
Thermal Conductivity	3.0w/m.k
Temperature resistance	1000℃
Density	5.65-6.05g/cm3
Thermal Expansion Coefficient	0.00001/℃
Bending Strength	480-1000MPa
Hardness (Hv)	1200-1450HV1
Fracture Toughness	*6-8MPam1/2**
Hazardous Substances	In compliance with EU ROHS standards

*This chart illustrates the standard characteristics of the zirconia materials commonly employed in the manufacturing of our zirconia products and parts. Please be aware that the attributes of customized zirconium oxide products and parts may vary depending on the specific processes involved. Detailed parameter is decided by type and composition of stabilizing agent.

Usage Instructions

1. Installation requirements

When install the zirconia metering pump, ensure that it's firmly fixed to avoid axial and radial movement;

2. Liquid temperature

The liquid temperature should be within the use temperature range to ensure the normal operation and accuracy of the metering pump;

3. Liquid properties

For liquid containing solid particles or high viscosity, it is necessary to pre-treat or select appropriate pump head;

4. Pump cleaning

Before or after each use, the pump body and related components should be cleaned in time to prevent residue deterioration in the pump body;

5. Regular maintenance

It is recommended to regularly check the pump plunger, seals and other parts wear, and timely replacement or adjustment if any wear that may affect the pump performance;

6. Pump storage

In the case that zirconia metering pump is not used for a long time, the pump should be cleaned and stored in a dry and cool environment.

Valuable Information

Customization Advantages

1. According to your application scenario, analyze the needs, choose the appropriate material and processing plan.

2. Professional team, quick response, can provide solutions and quotations within 24 hours after confirming the demand.

3. Flexible business cooperation mechanism, support at least one piece of quantity customization.

4. Quickly provide samples and test reports to confirm that the product meets your needs.

5. Provide product use and maintenance suggestions to reduce your cost of use.
